Specifications
|
WEW-100E
|
WEW-300E
|
WEW-600E
|
WEW-1000E
|
|
Maximum testing force
|
100kN
|
300kN
|
600kN
|
1000kN
|
|
Testing force measuring range
|
2%--100%FS
|
2%--100%FS
|
2%--100%FS
|
2%--100%FS
|
|
Testing force indication precision
|
±1%
|
±1%
|
±1%
|
±1%
|
|
Resolution
|
0.01mm
|
0.01mm
|
0.01mm
|
0.01mm
|
|
Deformation precison
|
±0.5%
|
±0.5%
|
±0.5%
|
±0.5%
|
|
Stretching space
|
550mm
|
600mm
|
620mm
|
620mm
|
|
Compression space
|
500mm
|
550mm
|
600mm
|
600mm
|
|
Gripping methos
|
Hydraulic (manul) gripping
|
Hydraulic gripping
|
Hydraulic gripping
|
Hydraulic gripping
|
|
Diameter of round specimen
|
φ6-φ26mm
|
φ6-φ30mm
|
Φ13-40mm
|
φ14-φ45mm
|
|
Thickness of flat specimen
|
0-15mm
|
0-15mm
|
0-30mm
|
0-40mm
|
|
Supporting roller distance of bending tests
|
500 mm
|
500 mm
|
600 mm
|
600mm
|
|
Host dimention
|
720×580×1950
|
720×580×1950
|
720×580×2100
|
890×660×2200
|
|
Net weight
|
1900 kg
|
1900 kg
|
2200 kg
|
2700 kg
|
